STP Profile Sanders/Denibbers are highly versatile machines equipped with a number and range of head variations to fit any application. Each spindle has a Wheel compensation, which further provides the operator with the means to account for wheel wear, resulting in the perfect finish every time. The STP series is designed to accommodate belts, formed wheels, and slit abrasive wheels. PLC control enables the ability to interface with other machines in the production line.
STP Linear Profile Sander/Denibber
Our STP series features a wide range of motion along with variable speed adjustment to precisely match your sanding requirements.
SPECIFICATIONS
| Sanding Stations | 4-10 wheels/belts with multi angle adjustment |
| Workpiece width | 1/2″ – 12″ |
| Workpiece length min. | 24″ |
| Workpiece thickness | 1/4″ – 4″ |
| Feed Speeds | up to 150 FPM |
| Feed System | 2 HP |
| Spindle motors | 3 HP |
| Spindle RPM | 600 – 1750 |
| Spindle diameter | 1″ |
| Spindle length | 9″-12” |
| Spindle angle adjustment | -45 to 135 degrees |
| Wheel diameter | 8″ |
| Wheel Compensation | Automatic air driven/adjustable ratchet drive |
| Sanding Stations | 4-10 wheels/belts with multi angle adjustment |
| Workpiece width | 1/2″ – 12″ |
| Electrical: | 480V, 3 ph, 60Hz |
ACCESSORIES
- Specialty wire brushes
- Vacuum table and blower
- High-grip, no-slip belt
- Close hold down rollers
- Bottom/side rollers and more
